The word “architect” is protected by law in the UK, only someone registered with the Architects Registration Board (ARB) can use the title.1 But that does not mean you always need one. For a significant proportion of domestic renovation and extension projects, an architectural technologist, a draughtsman, or even a specialist design-and-build firm will produce drawings that are equally fit for planning and building control purposes at considerably lower cost.

This guide explains what each professional does, what their drawings actually include, when you genuinely need a registered architect, and what you can expect to pay.

What an Architect Does

A registered architect is trained in the full lifecycle of a building project: concept design, planning strategy, technical design, specification writing, contract administration, and site inspection. To register with ARB, they must hold prescribed qualifications and have completed at least 24 months of practical experience under the direct supervision of a professional working in the construction industry.2 The usual route, from a first degree to the final Part 3 examination, takes around seven years.

For a homeowner, an architect’s key value propositions are:

  • Design quality, particularly for complex, unusual, or design-led projects where spatial creativity genuinely matters
  • Planning strategy, understanding what a particular LPA is likely to approve and how to frame a scheme to maximise its chances
  • Full project management, administering the building contract, certifying payments, and managing the contractor on your behalf

For straightforward extensions and loft conversions, however, the design problem is often not particularly complex, and many homeowners find that a competent architectural technologist delivers what they need.

Architect vs Architectural Technologist vs Draughtsman

Registered ArchitectArchitectural TechnologistDraughtsman
Protected titleYes (ARB)No (MCIAT and TCIAT are CIAT membership grades)No
TrainingUsually around 7 yearsTypically a degree plus professional experienceVariable
Design inputFull spatial designTechnical design focusPrimarily drafting
Planning drawingsYesYesYes
Building control drawingsYesYesSometimes
Contract administrationYesSomeRarely
Typical fee (extension project)8–15% of build cost or £3,000–£12,000£1,500–£5,000£600–£2,000

MCIAT is the designation of a Chartered Architectural Technologist, a member of the Chartered Institute of Architectural Technologists (CIAT).3 The HomeOwners Alliance puts typical UK architect fees at 3–15% of total construction cost, depending on the project’s size and complexity and how involved the architect is.4 The 8–15% in the table assumes a full service through to completion.

When to choose an architect

  • The project is design-led (unusual site, conservation area, listed building, contemporary self-build)
  • You want contract administration, someone to manage the builder formally on your behalf
  • Your LPA has a reputation for design scrutiny and you need a strong design narrative for planning
  • The project value exceeds roughly £150,000 and you want a professional accountable under contract

When an architectural technologist is usually enough

  • Straightforward rear extension or loft conversion following known typologies
  • Permitted development projects where the design parameters are already fixed by regulation
  • Budget-conscious projects where the saving of £2,000–£6,000 on professional fees is meaningful
  • You are willing to manage the builder yourself

When a draughtsman suffices

  • Planning drawings for a simple permitted development project where no building control drawings are needed immediately
  • Amendments to existing approved schemes
  • Small outbuildings or garage conversions where building control drawings are straightforward

RIBA Plan of Work: The Stages That Matter for Homeowners

The RIBA Plan of Work divides a project into eight stages (0–7).5 For a domestic extension, the stages you will pay for are:

StageNameWhat happensTypical fee proportion
0Strategic definitionFeasibility, brief, budget checkIncluded in Stage 1 or free
1Preparation & briefingSurveys, outline design options10–15%
2Concept designScheme design, planning application drawings20–30%
3Spatial coordinationTechnical design, structural coordination20–25%
4Technical designBuilding control drawings, specification20–25%
5Manufacturing & constructionSite inspections, contract administration20–25%
6HandoverSnagging, O&M manuals5%

Many homeowners instruct only up to Stage 4 (getting to building control drawings) and then manage the build themselves. This is perfectly reasonable for straightforward projects and reduces fees significantly.

Fee splits vary between practices. The HomeOwners Alliance gives a typical full-service split of 35% of the fee up to the planning application, 35% for technical design and tender, and 30% for construction to handover.4

Drawings for Planning Permission

A planning application for a householder extension requires:

  • Location plan based on an up-to-date map at a standard scale, typically 1:1250 or 1:2500, which you can buy through the Planning Portal’s accredited supplier6
  • Site plan (also called a block plan) at 1:200 or 1:500 showing the existing property footprint, boundary, and proposed extension footprint6
  • Existing and proposed floor plans. The national requirement is only that a plan is drawn to an identified scale; 1:50 and 1:100 are the conventional choices and what most councils’ validation lists ask for7
  • Existing and proposed elevations, which must also be drawn to an identified scale (again conventionally 1:50 or 1:100)7

These are not technically demanding drawings. A capable draughtsman or architectural technologist can produce them to a perfectly acceptable standard. The value an architect adds at planning stage is primarily in design quality and planning strategy, not in the drawings themselves.

Drawings for Building Control

Building control drawings are more technically demanding than planning drawings. They must show:

  • Foundation details (depth, width, formation)
  • Wall construction and U-values (insulation details)
  • Structural information (beam sizes, connection details)
  • Drainage connections
  • Fire compartmentation and means of escape
  • Ventilation and energy performance data

Your architect or architectural technologist produces these drawings in coordination with the structural engineer. Building control then reviews them before approving work on site. An architectural technologist is often more comfortable in this technical environment than a traditional architect whose strength is design.

How to Get a Quote

When seeking quotes, ask specifically what is included:

  1. How many design revisions are included before additional fees apply?
  2. Does the fee include dealing with planning queries and resubmissions?
  3. Are structural coordination and liaison with the structural engineer included?
  4. Does the fee include building control drawings, or only planning drawings?
  5. Is VAT included?

Always get quotes from three professionals and ask to see examples of their recent work on similar projects. Check that they carry professional indemnity (PI) insurance: ARB expects a registered architect to hold at least £250,000 of cover, on an each and every claim basis.8

Key Points

  • “Architect” is a protected title; “designer” and “draughtsman” are not.1 This does not mean unregistered professionals produce inferior drawings, many do excellent work.
  • For a straightforward extension or loft conversion, an architectural technologist (MCIAT) typically delivers everything a homeowner needs for considerably less than a full architect’s fee.
  • The fee split matters: instruct up to building control stage only if you are confident managing the build yourself.
  • Always agree in writing what is included, what triggers additional fees, and who owns the intellectual property in the drawings (this matters if you later switch professionals).

The rules in this note are those that apply in England. Scotland, Wales and Northern Ireland have their own building standards and permitted development rights.
